Project Description

FROM THE ARCHITECTS:

The 210,000 square-foot, elliptical shaped “Unisphere,” is the largest site-powered net zero commercial building in the US and houses clinical operations for pulmonary disease, heart failure, and organ transplantation as well as In Silico molecular biology – a virtual drug development lab.

This smart building takes advantage of multiple sustainability strategies. It has no operational carbon footprint because the electrical and thermal energy it uses is renewably generated on site. It is truly an engineering marvel.

Strategies employed to achieve Net Zero status include the following:

-3,000 solar or photovoltaic panels on the building generating 1,175 MWH of energy each year, enough to power 100 homes.

-The Earth Labyrinth is a quarter-mile-long concrete maze located twelve feet below Unisphere. This natural ventilation system, a collaboration between air and earth, moderates temperatures within the atrium as compared to the exterior climate.

-Beneath Unisphere, 52 closed-loop, dual-circuited geo-exchange wells are drilled 500 feet into the earth to provide energy storage.

-The atrium pool is used as a heat sink to help balance the overall system and provide passive heating of pool water.

-Daylight harvesting allows dimming of the artificial lighting system when adequate sunlight is available.

-The office area windows use electrochromic glass technology that changes tint level based on season, location of the sun, and cloud coverage.

-Operable windows and panels allow the building to naturally ventilate providing a completely passive ventilation mode between certain temperatures.

Excess power is sent back into the utility grid during peak production times, and the utility grid supplies this power back at night and at off-peak times.
